Page 41
1 – 26
7) Select pulselength and press the ENTER/SE-
LECT
key.
8) Press the ENTER/SELECT
key.
9) Press the MENU key.
Table 1-2 Default pulselength settings
e
g
n
a
R
5
7
.
0
5
.
1
3
6
2
1
4
2
t
e
S
L
P
1
.
o
N
P
1
M
P
1
M
P
2
M
P
L
P
L
P
L
t
e
S
L
P
2
.
o
N
P
S
P
S
P
1
M
P
2
M
P
L
P
L
Selecting pulselength set to use
Select pulselength set on P/L SEL of the ECHO
SIG menu.
1) Press the MENU key.
2) Select the ECHO SIG menu.
3) Press the ENTER/SELECT
key.
4) Select P/L SET and press the ENTER/SE-
LECT
key.
5) Select P/L1 (or P/L2).
6) Press the ENTER/SELECT
key.
7) Press the MENU key.
1.35 Waypoint Display
A waypoint selected on a radionav equipment can
be displayed on the radar. This function requires
a compass signal.
1) Press the MENU key.
2) Select the INITIAL menu.
3) Press the ENTER/SELECT
key.
4) Select NAV DATA and press the ENTER/SE-
LECT
key.
5) Select EXT WP and press the ENTER/SE-
LECT
key.
6) Select ON (or OFF).
7) Press the ENTER/SELECT
key.
8) Press the MENU key.
NR
IR2
ES1
EAV1
0.080nm
0.220nm
TRU TRAIL
30M
GUARD1
GUARD2
IN
0.25
NM
0.05
ZOOM
SP
HU
A/C
F3
L-ES
345.6°R
23.0°R
29:59
+
105.0°R 00.74nm
AUTO
00:45
VRM
EBL
SPEED
MANUAL 30.0kt
HDG 123.4°
TTG
12:34
External
waypoint
Figure 1-28 Displaying an external waypoint
1.36 Outputting Cursor Position
(TLL data)
Cursor position can be output to external equip-
ment, in IEC 1162 format, by pressing the VRM
(TLL) control. This function requires position
data and a compass signal.
