FireplaceXtrordinair 864 HH User Manual
Page 3
Introduction
3
© Travis Industries
4080218
100-01181_003
Table of Contents
Introduction and Important Information
Introduction ............................................................. 2
Important Information ............................................... 2
Installation Warnings ................................................ 2
Features ................................................................. 3
Heating Specifications .............................................. 3
Safety Precautions
Safety Precautions ................................................... 4
Operation
Before You Begin ..................................................... 6
Location of Controls ................................................. 6
Starting The Pilot Flame ............................................ 6
Starting the Fireplace for the First Time....................... 8
Turning the Fireplace On and Off ................................ 8
Adjusting the Flame Height........................................ 8
Adjusting the Blower Speed ........................................ 9
Instruction Card ....................................................... 9
Normal Operating Sounds.......................................... 9
Normal Operating Odors............................................ 9
Maintenance
Maintaining Your Fireplace's Appearance..................... 10
Yearly Service Procedure.......................................... 10
Grill Installation and Removal .................................... 11
Face Installation and Removal................................... 12
Glass Frame Removal and Installation........................ 13
Log Set Installation .................................................. 15
Glass Cleaning ........................................................ 19
Troubleshooting Table ............................................... 20
How this Fireplace Works .......................................... 21
Wiring Diagram........................................................ 22
Replacement Parts List ............................................ 23
Warranty
Warranty ................................................................ 24
Optional Equipment
Optional Equipment List ............................................ 25
Index
Index...................................................................... 26
Features
•
Works During Power Outages (millivolt system)
•
Optional Thermostat or Remote Control
•
Realistic "Wood Fire" Look
•
Built-in Blower for Effective Heat Distribution
•
Convenient Operating Controls
•
Variable-Rate Heat Output
•
Low Maintenance
Heating Specifications
Natural Gas
Propane
Approximate Heating Capacity (in square feet)*
1,200 to 2,250
1,200 to 2,250
Maximum BTU Input Per Hour
40,000
39,000
*
Heating capacity will vary with floor plan, insulation, and outside temperature.
