SERIES II 15 AMP PowER CondItIonERS
heavy-duty power cable.
O P E R AT I O N
Retractable Rack Lights, Rear Panel Lamp
and dimmer Control:
The PL-8 II, PL-Plus, and PL-Plus D II utilize
a dimmer control for the two retractable front
panel light tubes. The dimmer knob controls
the brightness of both light fixtures. Turn
it clockwise to increase brightness; turn it
counterclockwise to decrease brightness.
When the lights are not in use, we recommend
turning the dimmer fully counterclockwise to
maximize the life of the LED’s, however, this
is not absolutely necessary. Whether the light
tubes are retracted or flush with the front panel,
there will be no appreciable heat regardless of
dimmer setting due to the efficiency of our full
light spectrum LED’s.
All Series II units feature a rear rack BNC
socket which will accept any 12 VAC (0.5A)
gooseneck lamp assembly, (such as the
Furman GN-LED or GN-I). Simply slide the
BNC plug over the socket and rotate clockwise
until the connector snaps into the locked
position. The rear rack lamp can be powered on or
off with the rear light power switch located on the far
left of the front panel. The Series II’s front panel
LED lamps must be replaced by qualified
Furman service personnel.
Multi-Segment LEd voltmeter:
(PL-Plus II only)
This three-color, 20-LED bargraph is an
accurate, self checking AC voltmeter that
continually measures normal voltages. The
meter reads from 90 to 128 volts in 2 volt
increments (PL-PLUS E II: 180 to 256 volts, in
4 volt increments). The normal range voltages
are indicated in green, with moderate and
extremely high or low voltages in yellow and
red respectively. The voltmeter provides three
special flashing patterns to indicate abnormal
conditions.
(1) If only the single leftmost (beneath the
90V mark – 180V for E version) LED
flashes, the input voltage is marginally
low.
(2) If all of the LED’s on the voltmeter
flash, the input voltage is marginally
high. Power to the PL-Plus’s outlets
will remain unless the incoming voltage
rises above the Extreme Voltage
5
Mains Vltg. Voltage Status Voltmeter Reading Outlets
80-90 Low Marginal The LED beneath the 90V mark flashes ON
90-104 Low Meter Reads in Low Red ON
106-108 Medium Low Meter Reads in Low Yellow ON
110-120 Normal Meter Reads in Green ON
122-124 Medium High Meter Reads in High Yellow ON
126-128 High Meter Reads in High Red ON
130-140 High Marginal All Meter LEDs Flash ON
Above 140 Extreme (Shutdown) Meter off—Extreme Voltage LED illuminates OFF
