2.3 Troubleshooting Data Array Maps
Current Point Status
Data Array
Offset
Function
0 Function Code always 55
1 Current Date: Year
2 Current Date: Month
3 Current Date: Day
4 Current Time: Hour
5 Current Time: Minute
6 Current Time: Second
7 Gas Abbreviation Code
8 Gas Abbreviation Code
9 Gas Abbreviation Code
10 Gas Abbreviation Code
11 Gas Abbreviation Code
12 Gas Abbreviation Code
13 Gas Abbreviation Code
14 Gas Abbreviation Code
15 Gas Abbreviation Code
16 Gas Abbreviation Code
17 Gas Abbreviation Code
18 Gas Abbreviation Code
19 Format Code
20 Current Flow
21 Time and Date TWA Start Current Date: Year
22 Time and Date TWA Start Current Date: Month
23 Time and Date TWA Start Current Date: Day
24 Time and Date TWA Start Current Time: Hour
25 Time and Date TWA Start Current Time: Minute
26 Time and Date TWA Start Current Time: Second
27 Time and Date TWA End Current Date: Year
28 Time and Date TWA End Current Date: Month
29 Time and Date TWA End Current Date: Day
30 Time and Date TWA End Current Time: Hour
31 Time and Date TWA End Current Time: Minute
32 Time and Date TWA End Current Time: Second
33 TWA Concentration
34 Last Concentration
35 Alarm Status
