FS-8700-54 MDA CM4 Driver Manual
FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 2
2. FieldServer as a Zellweger CM4 Client
2.1 Hardware Connections
Refer to the Drawings in section 4
Configure the CM4 according to manufacturer’s instructions
2.2 Configuration File Structure
The following tables describe parameters that need to be filled out in the configuration file. For
convenience, a few example parameters already exist in the supplied PRIMSERV.CSV and
SECDSERV.CSV files.
Note that * indicates an optional parameter, with the bold legal value being the default.
2.2.1 Data Arrays
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array Up to 32 alphanumeric characters
Data_Format Provides data format INT16, INT32, BIT, FLOAT
Data_Array_Length Number of Data Objects 1-10,000
Example:
Data_Arrays
Data_Array_Name, Data_Format,
Data_Array_Length
DA_AI_01, Uint16, 100
DA_AI_02, Uint16, 100
DA_AI_03, Uint16, 100
DA_AI_04, Uint16, 100
DA_AI_11, Uint16, 100
DA_AI_21, Uint16, 100
