Profiles.
You are now in the program profiles. The controller has 9 operating programs – Pre Chill, Soft Chill, Hard Chill, Hard Chill
Max, Shock Freeze, Professional 1, Professional 2, Professional 3, Defrost and 2 optional programs – UV Sanitisation
and Information. These programs are all available depending upon which of the profiles are selected, see below.
To change the profile rotate the dial to select program, press and release the dial to accept the change. The 3 chevrons in
the box opposite the selected program confirm the change.
The default operating profile for the RBC20-60 and RBC20-60R is ‘LE CHEF’.
The table identifies which programs are available from the profile with ‘LE CHEF’ highlighted.
PROFILES
PROGRAMS
SIMPLE SIMPLE + CHEF CHEF+ LE CHEF EXPERT EXPERT+
PRE CHILL U U U U 9 9 9
SOFT CHILL U U 9 9 9 9 9
HARD CHILL
9 9 9 9 9 9 9
HARD CHILL MAX
U U 9 9 9 9 9
SHOCK FREEZE U 9 U 9 U U 9
PROFESSIONAL 1 U U U U U 9 9
PROFESSIONAL 2 U U U U U 9 9
PROFESSIONAL 3 U U U U U 9 9
DEFROST
9 9 9 9 9 9 9
UV SANITISATION OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL
INFORMATION OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL OPTIONAL
Parameter Access.
From the profile screen once the selection has been made press and release the dial to access the parameter list. The
screen will display the parameters as shown in the screen below left. To access the system parameters rotate the dial
anticlockwise see below right.
Selection is made by pressing and releasing the dial.
The table below contains the complete parameter list and includes the selectable range and default values.
Parameters
PARAMETER
DESCRIPTION VALUE MINIMUM MAXIMUM DEFAULT
PRE-CHILL
PO1 AIR TEMP °C -15 15 -10
PO2 CHILL TIME MINUTES 5 60 15
PO3 HOLD TEMP °C -10 15 3
SOFT-CHILL
PO4 AIR TEMP °C -10 15 1
PO5 CHILL TIME MINUTES 5 480 90
PO6 CHILL TEMP °C -5 15 3
PO7 HOLD TEMP °C -5 15 3
HARD CHILL
PO8 AIR TEMP °C -20 15 -15
PO9 CHILL TIME MINUTES 5 480 90
P10 CHILL TEMP °C -15 15 3
P11 HOLD TEMP °C -15 15 3
P12 CHANGE TIME % 5 95 80
P13 CHANGE TEMP % 5 95 80
