PARTS PICTURE

D

N8417pr-0920

7

5

20

24

7

8

15

6

11

18

9

16

2

13

14

3

4

Note: Some parts shown are assembled on both sides of the vehicle.

17

10

21

12

11

23

19

25

1

Vehicle

2

Front

End

3

Bumper

4

Headlight Covers - 2

5

Headlights - 2

6

Doors - 2

7

Hood

8

Windshield/Dash

9

Door Plates - 2

10

Seat

11

Short Seat Belts - 2

12

Long Seat Belt

13

Wings - 2

14

Front Wheels - 2

15

Wheel Covers - 2

16

Hubcaps - 2

17

Bushing - 2

18

Truck Bed

19

Steering Wheel

20

Steering Column

21

Taillight - 2

22

12 Volt Charger

23

12 Volt Battery

24

Key Assembly

3

/

8

"-16 Lock Nuts - 2

1

/

4

" x 1

1

/

4

" Screws - 2

#8 x

3

/

4

" Screws - 34

Label Sheet

7

/

16

" Washers - 2

Assembly Tool

Parts Not Shown

25

Steering Column Cap

26

Steering Wheel Cap

27

5

/

32

" x 1

1

/

2

" Pin - 1

26

27

22

1
