864TRV Arched Face
Classic Black: 99300497 Artisan: 99300498
French Country Black: 95800616 Artisan Patina Bronze 95800621
Page 4 of 4 17601406 - 9/14/11 © Travis Industries, Inc.
3 Install the face following the directions below.
Attach the upper brackets
to the face with the
included nuts.
Slide the face into place. The
tabs on the upper brackets insert
into the slots on the fireplace
brackets, holding the face in place
while the screws are tightened.
a
b
c
The face is secured to the fireplace
with four screws. Two of the screws
are fastened to the upper brackets
with press nuts. The lower screws
are included with the face.
Plated Surfaces
Use denatured alcohol and a soft cloth to clean plated surfaces. Marks
left on the surface may damage the face.
Denatured
Alcohol
Soft Cloth
