Fisher-Price GRAVE DIGGER H0436 - Manual (Page 9)

9
ASSEMBLY E
H0436pr-0920
8
• Slide the sounds and
lights unit into the dash,
as shown.
• Plug the sounds and lights unit connector into the vehicle connector.
Hint: If the connectors do not fit together, do not force them. Simply
turn one of them over and try again.
9
• Insert two #8 x 1" black screws into the sounds and lights unit.
Tighten the screws.
Assembly is now complete.
Sounds and
Lights Unit
Sounds and
Lights Unit
Wire
Connectors
