ASSEMBLY E
H0436pr-0920
2
• Insert two #8 x 1" black screws through one side of the seat and
into the floorboard of the vehicle. Tighten the screws.
3
• Insert two #8 x 1" black screws through the other side of the seat
and into the floorboard of the vehicle. Tighten the screws.
5
• Open the trunk. Insert six #8 x 1" black screws into the trunk
and tighten.
Seat
Floorboard
Floorboard
Seat
Trunk
Door
Trunk
Left Side View
Right Side View
Back View
4
• Insert a #8 x
3
/
4
" chrome screw into the hole in the seat near the
shifter. Tighten the screw.
Inside View
Shifter
Seat
