ASSEMBLY
11
12
• Fit a 3 /
8
" -16 hex nut onto each end of the front axle. Tighten both
hex nuts with the wrench.
Front Axle
• Fit a wheel, rib side in, onto the front axle.
• Slide a hubcap, peg side in, onto the front axle.
Hubcap
(Peg Side In)
Wheel
(Rib Side In)
Front Axle
• Turn the vehicle upright.
• Insert the tabs on the front edge of the seat into the floor
of the vehicle.
Seat
Tabs
• Fit and snap a hubcap cover to the hubcap.
• Repeat Assembly steps 10-13 to assemble a washer, bushing,
wheel, hubcap, hex nut and hubcap cover to the other front axle.
Hubcap
Cover 13
14
FRONT VIEW
3 /
8
" -16 Hex Nut
Wrench
