23 105073
OWNER’S MANUAL
PARTS LIST
VFP18R
VFP24R
VFP30R
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 21 of this manual.
KEY PART NUMBERS
NO. VFP18R VFP24R VFP30R DESCRIPTION QTY.
1L 105241-01 105241-02 105998-01 Left Front Log (#1L) 1
1R _____ 105241-03 105999-01 Right Front Log (#1R) 1
2 105243-01 105243-02 106000-01 Bottom Middle Log (#2) 1
3 105245-01 105245-02 106001-01 Rear Log (#3) 1
4 105249-01 105249-02 106002-01 Top Middle Log (#4) 1
5 105247-01 105247-02 106003-01 Crossover Log (#5) 1
6 103778-01 103778-01 103778-01 O.D.S. Pilot 1
7 098249-01 098249-01 098249-01 Nut 6
8 103780-01 103780-01 103780-01 Pilot Bracket 1
9 101330-01 101330-05 101330-06 Front Burner Assembly 1
9-1 101008-01 101008-01 101008-01 Crossover Burner Gasket 1
9-2 101007-01 101007-01 101007-01 Crossover Burner 1
10 100999-02 100999-02 100999-03 Rear Burner Assembly 1
11 103984-01 103984-02 103984-03 Base Assembly and Decal 1
12 098271-06 098271-06 098271-06 Ignitor Cable 1
13 102445-01 102445-01 102445-01 Piezo Ignitor 1
14 103588-01 103588-01 103588-01 Heat Shield 1
15 103782-01 103782-01 103782-01 Valve Bracket 1
16 M12461-26 M12461-26 M12461-26 Screw 5
17 103781-02 103781-02 103781-02 Gas Control 1
18 098264-02 098264-02 098264-02 Male Fitting 1
19 103784-02 103784-02 103784-02 Flame Adjustment Knob 1
20 103784-01 103784-01 103784-01 Control Knob 1
21 103587-01CK 103587-01CK 103587-01CK Switch Plate 1
22 M11084-26 M11084-26 M11084-26 Screw 2
23 103284-02 103284-02 103284-02 Wiring Harness 1
24 099387-09 099387-09 099387-09 Pilot Tube 1
25 101004-10 101004-01 101004-02 Rear Burner Injector 1
26 101004-10 101004-02 101004-06 Front Burner injector 1
27 103783-01 103783-01 103783-01 Remote Burner Tube 1
28 099998-01 099998-01 099998-01 Switch 1
29 M11084-26 M11084-26 M11084-26 Screw 6
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 Warning Plate 1
103877-01 103877-01 103877-01 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 Caution Decal 1
101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 Lava Rock 1
