Appendix B. Reference

Appendix B.1. Command Support

The following commands are supported by the FieldServer for the various PLC types:

PLC_Type File_Type FNC Read

FNC Write

Typical
Command

PLC3

N

1

Range Read

0

Range Write

N7: 3, L5

F

1

Range Read

0

Range Write

F12: 3, L5

B

1

Range Read

2

Bit Write

B3/4: 5, l5

PLC5

N

1

Range Read

0

Range Write

N7: 3 , L5

F

1

Range Read

67

Typed Write

F12: 3, L5

B

1

Range Read

26

Read Modify Write

B3/4: 5, L5

SLC5

N

A2

Protected Typed Logical
Read

AA

Protected Typed Logical
Write

N7: 3, L5

F

A2

Protected Typed Logical
Read

AA

Protected Typed Logical
Write

B3/4: 5, L7

B

A2

Protected Typed Logical
Read

AB

Protected Typed Logical
Write

B3/4: 5, L8

I

A2

Protected Typed Logical
Read

-

-

I: 13, L5

O

A2

Protected Typed Logical
Read

-

-

O: 13, L5

Appendix B.2. Error Messages

DF1 Rem STS err F0-> Extended error code – Refer to following table.
