FS-8700-03 DF1 Driver Manual Page 10 of 16
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
6 CONFIGURING THE FIELDSERVER AS A DF1 SERVER
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a DF1 Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for DF1 communications, the driver independent FieldServer buffers need to be declared in the
“Data Arrays” section, the FieldServer virtual node(s) needs to be declared in the “Server Side Nodes” section, and
the data to be provided to the Clients needs to be mapped in the “Server Side Map Descriptors” section. Details
on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
6.1 Server Side Connection Parameters
Section Title
Connections
Column
Title
Function Legal Values
Port
Specify which port the device is connected to the
FieldServer
P1-P8 6
Baud* Specify baud rate 300 to 115200; 9600
Parity* Specify parity Even, Odd, None
Data_Bits* Specify data bits 8
Stop_Bits* Specify stop bits 1, 2
Protocol Specify protocol used
DF1_FD, DF1_HD_MASTER,
DF1_HD_SLAVE
Checksum Specify Checksum – refer to Appendix A.2 BCC, CRC-16
Example
// Server Side Connections
Connections
Port , Protocol , Baud , Parity , Data_Bits , Stop_Bits
P1 , DF1_FD , 38400 , None , 8 , 1
6 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
