B+ (Yellow)
Connect where the power is constantly available, regardless of the ignition key's position.
Ground (Black)
Connect where good body grounding is available.
DVD MUTE wire (Pink)
Connect to H/A MUTE or DVD MUTE on the main unit.
NAVI MUTE wire (Brown)
Connect to NAVI MUTE on the navigation unit.
Front speaker output leads
Connect to the front speakers.
White:
Left +
White/Black:
Left -
Gray:
Right +
Gray/Black:
Right -
Rear speaker output leads
Connect to the rear speakers.
Green:
Left +
Green/Black:
Left -
Purple: Right +
Purple/Black:
Right -
6
5
4
3
2
1
- 6 -
Wire colors and connection points for connection cables
2
Never connect the power supply to the speaker leads (No.5 and No.6),
otherwise it will cause damage to the main unit.
Caution
E-LAN terminal
Connect to the main unit or to a CD changer (sold separately) if one is being used with the system.
Line-out terminal (Front Mid-Low)
Line-out terminal (Front / Front Mid)
Line-out terminal (Front Hi)
Line-out terminal (Rear)
Connect to the RCA input Connectors of an external amplifier.
White : Left signal
Red : Right signal
A
B
C
D
Main unit connectioms
If not using
and
, insulate
them using PVC tape or similar.
If they are not insulated, incorrect
operation may result.
4
3
Connect to the RCA input Connectors of an external
amplifier.
White : Left signal
Red : Right signal
E
*
The speakers to connect will vary depending on whether the speaker layout is
•
1-way speaker
•
or
•
3-way speaker. (Refer to the instruction manual for details on switching the speaker layout.)
•
• If the speaker layout is "1-way speaker":
Use the "LINE OUT" (Front/Front/Mid) terminal .
Terminals and are not used.
•
• If the speaker layout is "3-way speaker":
Connect to the low-range speaker (woofer), connect to the mid-range speaker
(squawker), and connect to the high-range speaker (tweeter).
C
B
D
B
C
D
