FORD 2005 F-150 - Manual (Page 227)

Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
10 20A* Trailer tow back-up lamps relay
(PCB1), Trailer tow parklamp relay
(R201)
11 10A* A/C clutch, 4x4 solenoid
12 — Not used
13 10A* Climate control module power,
Flasher relay
14 10A* Back-up lamp and Daytime Running
Lamps (DRL) relay coil, A/C pressure
switch, Redundant speed control
switch, Heated PCV (5.4L), Trailer
tow back-up lamps relay coil, ABS,
Reverse park aid, EC mirror
15 5A* Overdrive cancel, Cluster
16 10A* Brake-shift interlock solenoid
17 15A* Fog lamp relay (R202)
18 10A* Run/Start feed - Overhead power
point, Electrochromatic mirror,
Heated seats, BSM, Compass, RSS
(Reverse Sensing System)
19 10A* Restraints (Air bag module)
20 10A* Battery feed for overhead power point
21 15A* Cluster keep alive power
22 10A* Delayed accessory power for audio,
power door lock switch and moonroof
switch illumination
23 10A* RH low beam headlamp
24 15A* Battery saver power for demand
lamps
25 10A* LH low beam headlamp
26 20A* Horn relay (PCB3), Horn power
2005 F-150 (f12)
Owners Guide (post-2002-fmt)
USA (fus)
