C
ONSOLE
P
ORT
P
IN
A
SSIGNMENTS
February 2003
© 2003 Foundry Networks, Inc.
B-7
Console Port to 25-Pin DTE Port on PC
Switch’s 9-Pin Serial
Port
Null Modem
PC’s 25-Pin DTE
Port
2 RXD
<---------RXD ------------
2 TXD
3 TXD
-----------TXD ---------->
3 RXD
5 SGND
-----------SGND ----------
7 SGND
No other pins are used.
