February 2003 © 2003 Foundry Networks, Inc. 2-1
C
HAPTER
2
A
BOUT THE
E
DGE
I
RON
4802CF
Overview
Foundry’s EdgeIron 4802CF is an intelligent Fast Ethernet switch with 48
10BASE-T/100BASE-TX ports and two 10/100/1000BASE-T combo
ports that operate in combination with 2 Small Form Factor Pluggable
(SFP) transceiver slots. This switch can easily tame your network with full
support for Spanning Tree Protocol, Multicast Switching, Virtual LANs,
and Layer 2/3/4 CoS services.
Figure 2-1. Front and Rear Panels
System Indicators 10/100 Mbps RJ-45 Ports Mode Select Button Port Status Indicators Console Port
Redundant Power Socket Power Socket
1000BASE-T/SFP Ports
