Fluid Ford Part
Name Application
Capacity
Fuel tank N/A Regular cab
(Short wheel
base)
62.8L (16.6 gallons)
Regular cab
(Long wheel
base) 75.7L (20.0 gallons)
SuperCab 74.2L (19.6 gallons)
Transfer
Case Fluid Warner 13–54 4x4 Vehicles
1.2L (1.25 quarts)
Front axle
fluid Motorcraft SAE
80W90 Axle
Lubricant 4x4 vehicles with
2.5L I4 or 3.0L
V6 engine
1.4L (1.5 quarts)
4x4 vehicles with
4.0L V6 engine 1.7L (1.8 quarts)
Rear axle
fluid
1
Motorcraft SAE
80W90 Rear
Axle Lubricant All
2.4-2.6L
(2.5-2.65 quarts)
Windshield
washer fluid Ultra-Clear
Windshield
Washer
Concentrate All
Fill to line on
reservoir
1 Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546–A, Ford
specification EST-M2C118–A for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Capacities and specifications
149
