TB14 SERIES GAS FRYERS
CHAPTER 9: PARTS LIST
9-9
9.6 Frypot, Burners and Related Components (cont.)
ITEM PART # COMPONENT
1 826-1871 Frypot, SS- 1-¼" Drain System
2 200-1329 Bracket, Burner Mounting
3 200-1330 Shield, Burner Heat
4 823-3522 Diffuser, TB14
5 810-2150 Burner, Right
6 810-2149 Burner, Center
7 810-2151 Burner, Left
8 200-1615 Support, Manifold- Left and Right
9 809-0822 Bolt, ¼-20 x ½"
10 809-0823 Nut, Nylock- ¼-20
11 813-0154 Plug, Hex- 1/8" NPT
12 810-2048 Orifice #39 (2.53 mm)- Natural
* 810-2059 Orifice #53 (1.51 mm)- LP
13 810-2130 Manifold, Gas
14 810-2156 Valve, Gas- Robertshaw Natural
* 810-2323 Valve, Gas- Robertshaw LP
15 813-0109 Nipple, ¾" x Close NPT BM
16 813-0066 Elbow, ¾" 90° NPT BM
17 813-0119 Nipple, ¾ x 4" NPT BM
18 813-0168 Elbow, Street- ¾" 90° NPT BM
19 813-0174 Union, ¾" NPT BM
20 813-0165 Elbow, Street- 90° ½" NPT BM
21 813-0793 Nipple, ½ x 19-½" NPT BM
22 810-2043 Clamp, Pipe- ½" BM Pipe
23 809-0821 Screw, Pipe Clamp- ¼-20 x ¾ Hex
24 813-0031 Bushing, Hex- ½ to ¾" NPT BM
25 810-2126 Valve, Drain- 1-¼" Full-Port (Includes Washers and Nuts)
26 210-2029 Stop, Valve Handle (Activator)
27 200-1940 Actuator, Drain Handle Arm Push-Pull
28 200-1257 Retainer, Valve Handle Nut
29 813-0391 Nipple, 1-¼ NPT x Close BM
30 823-3801 Elbow Bracket Assembly, Drain Valve
31 813-0348 Nipple, Toe- 1-¼ x 6-1/8"
32 823-3429 Handle, Drain Valve
33 809-0885 Washer, Drain Valve Handle
34 809-0843 Pin, Cotter- Drain Valve Handle
35 816-0547 Cap, Red Vinyl- Drain Valve Handle
36 810-2032 Burner, Pilot- Natural
* 810-2155 Burner, Pilot- LP
37 810-0703 Gas Line, Pilot- ¼ x 17-½"
38 807-3550 Thermocouple
* 810-2033 Thermopile
* Not Illustrated
