TB14 SERIES GAS FRYERS
CHAPTER 9: PARTS LIST
9-7
9.5 Filter Pan Components
1
2
3
4
5
6 7
8
9 10
11 12
ITEM PART # COMPONENT
1 106-2257SP Pan Assembly, Filter- SUFF 50
2 810-0006 Caster- 2"
3 809-0822 Bolt, ¼-20 x ½" Steel
* 809-0820 Nut, ¼-20 Oval Locking
4 210-2291 Insert, Caster Mount
5 809-0805 Screw, ¼-20 x ½"
6 813-0679 Plug, 1/8" SS Square Head (Female Disconnect)
* 813-0684 Plug, 3/8" SS Hex (Pan Pick-up Tube)
7 823-3736 Basket, Crumb Catcher
8 823-3790 Grid, Filter Pan
9 803-0317 Paper, Filter
* 803-0002 Powder, Filter
10 823-3795 Ring, Hold-Down (Filter Paper)
11 823-3798 Lid, Filter Pan- Rear
12 823-3797 Lid, Filter Pan- Front
* Not Illustrated
