FELLOWES 520 - Manual (Page 5)

Edition 01/03 5
520
Paper shredder 520C
3. Technical Specifications
Model 520 Model 520C
Cutting style Strip cut Cross cut
Shred size 5/32" 1/4" 5/32" x 2"
(3.9 mm) (5.8 mm) (3.9 x 50 mm)
*Sheet capacity -
U.S. (75 g/m
2) 28 38-40 26-28
Europe (70 g/m 2 ) 35 50 32
Speed 32 FPM 25 FPM
(143 mm/s) (100 mm/s)
Entry width 16"(400 mm)
Motor power 120 V / 60 Hz units: 2.25 HP
230/240 V / 50 Hz units: 1,6 kW
Input voltage 120 V, 60 Hz
(Depending on country) 230 V, 50 Hz
Dimensions (H x W x D) 36 1 / 4 " x 23 1 / 2 " x 18 1 / 2 "
(921 x 597 x 470 mm)
Weight 179 lbs. (81 kg) 206 lbs. (93 kg)
Waste container volume 41.2 gallons (156 liters)
Noise level In idle 60dB
Under load 68 dB strip cuts and 75 dB cross cuts
*
Paper DIN 19307 SM 4a – 70
