Frymaster CT16 Series - Manual (Page 21)

2-7
ITEM PART # COMPONENT
1 106-2123SP Tray with Grommet, VT Platen
2 210-0318 Crumb Shield, Toasting Conveyor
3 806-9195 Roller, VT Toasting Belt Idler
4 806-9196SP Platen Assembly, VT
5 806-9199 Roller, VT Toasting Belt Drive
6 810-2303 Washer, Teflon Crumb
7 809-0266 Screw, #10 x ½-inch Philips Truss Head
8 809-0647 E-Ring
9 809-0650 Screw, 10-32 x ⅜-inch Button Socket Head
10 809-0745 Washer, ¼-inch Flat
11 810-1721 Shaft, Long Roller
12 810-1736 Plug, 1.75-inch Stainless Button
13 810-1776 Pin, VT Cotter
14 810-1818 Spring, 3-inches Long, 4.6 Lbs./Inch
15 810-2305 Bushing, Roller
16 816-0379 Belt, Toasting
17 816-0403 Insulation, Platen
18 823-2726 Slide Assembly, Belt Tension
19 910-8246 Guide, Crumb Shield
20 910-8254 Brace, VT Platen Tray
* 21* 910-8512 Bracket, Slide Assembly Receiver
22 810-1722 Grommet, .5-inch I.D. x 1.05-inch O.D. (Integral component of Item 1)
23 810-2013 Roller, VT Drive (Integral component of Item 3)
24 810-1810 Bushing, Teflon (Integral component of Item 3)
25 807-3037 Thermostat, High-Limit (Integral component of Item 4)
26 910-8637 Spacer, High-Limit Thermostat (Integral component of Item 4)
27 809-0729 Capscrew, 6-32 x ¼-inch Socket Head (Integral component of Item 4)
28 807-3247 Probe, Heater (Integral component of Item 4)
29 910-8757 Retainer, Heater Probe (Integral component of Item 4)
30 826-1330 Screw, 10-32 x ⅜-inch Slotted Truss Head (Integral component of Item 4)
31 810-1658 Platen, 5000W (Integral component of Item 4)
* Obscured by Item 1. See Item 24 on Page 5 for illustration.
