5-6
Square are highlighted as
corresponding keys are pressed.
These squares are for
ST-BY, DEGAUSS and
AUTO/MAN TUNE
switches from above.
Two lines are for control panel.
FR-2005 TEST
PROGRAM NO
ROM RAMCRAM DIPSW
MAIN XXXXXXXXXXX
OK
OK
OK
1111
SUB XXXXXXXXXX
OK
OK
ARP XXXXXXXXXX
OK
OK
OK
0000
DSP XXXXXXXXXX
OK
OK
OK
RP XXXXXXXXXX
OK
OK
OK
1000
DRAM
RP BOARD BAT OK
RP CARD1 OK CARD2
OK
VRAM 1 2 3 4 5 6 7 8
