Fcn-086 / 087 series
Dimensions are in millimeters (inches) www.fcai.fujitsu.com
Specifications
subject to change
The contact pins have a three-level sequence structure and can be connected/disconnected in an ac-
tive state. The terminal side can support various applications with four types of length. These combi-
nations allow 20 types of terminals.
Relationship between housing and terminals
Terminal types in the series
n terminal conFiguration oF plug
PC Board Face
Contact Types
Contact length
Lead length
PWB Surface
Contact length
Lead length
PWB Surface
