Wiring
Refer to the interconnection diagram at the back of this manual and the illustration below.
1
2
3
4
5
6
7
IF-1500AIS
J1:AIS IN
TD A
TD B
RD H
RD C
SIG. GND
SIG. GND
F.G. RD A
RD B
TD A
TD B
ISO GND
F.G.
1
2
3
4
5
6
7
IF-1500AIS
J1:AIS IN
TD A
TD B
RD H
RD C
SIG. GND
SIG. GND
F.G. RD H
RD C
TD A
TD B
N.C
N.C
F.G.
YEL
GRN
WHT
BLK
MJ-A7SPF0003-050
MJ-A7SPF0003-050
AIS
External display
Aux. display -
-
- Pilot plug
AIS
External display
Aux. display
Pilot plug
RED
BLU
YEL
GRN
WHT
BLK
RED
BLU
For IEC 61162-2
For IEC 61162-1, NMEA-0183
-
-
-
Notice:
Do not connect "SIG. GND" of the IF-1500AIS
to "Frame Ground".
ISO GND
Notice:
Do not connect "SIG. GND" of the IF-1500AIS
to "Frame Ground".
