Signamax
™
065-7710 8-Port 10/100BaseT/TX + 2SFP Managed Switch
Publication date: January, 2006
Revision A1
233
set pvid
Syntax:
set pvid
Description:
To set vlan PVID and port pripority.
Argument:
: which port(s) you want to set PVID(s).
Syntax 1,5-7, available
from 1 to 10
: which PVID you want to set, available from 1 to 4094
: which priority you want to set, available from 0 to 7
Possible value:
: 1 to 10
: 1 to 4094
: 0 to 7
Example:
065-7710(vlan)# set pvid 3,5,6-8 5 6
set tag-group
Syntax:
set tag-group
Description:
To add or edit the tag-based vlan group.
Argument:
: vlan id, from 1 to 4094
: tag-vlan group name
: member port; syntax: 1,5-7, available from 1 to 10
: untagged out port; syntax: 1,5-7, available from 0 to 10
set untag_range to 0 as none of the ports are force untagged
Possible value:
: 1 to 4094
: 1 to 10
: 0 to 10
Example:
065-7710(vlan)# set tag-group 2 vlan-2 2-8 0
