Signamax
™
065-7710 8-Port 10/100BaseT/TX + 2SFP Managed Switch
Publication date: January, 2006
Revision A1
226
set trunk
Syntax:
set trunk
Description:
To set up the status of trunk, including the group number and mode of the trunk as
well as LACP mode.
Argument:
: syntax 1,5-7, available from 1 to 10
:
static : adopt the static link aggregation
lacp : adopt the dynamic link aggregation- link aggregation control protocol
: 1-3
:
active : set the LACP to active mode
passive : set the LACP to passive mode
Possible value:
: 1 to 10
: static or lacp
: 1-3
: active or passive
Example:
065-7710(trunk)# set trunk 2-5 lacp 1 active
show aggtr-view
Syntax:
show aggtr-view
Description:
To display the aggregator list.
Argument:
None.
Possible value:
None.
Example:
065-7710(trunk)# show aggtr-view
Aggregator 1) Method: None
Member Ports: 1
Ready Ports:1
Aggregator 2) Method: LACP
Member Ports: 2
Ready Ports:
:
:
:
