CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Copyright 2009 Firstech, LLC. Page 21
Special Option Group 1
Feature Setting Value (Seconds)
1
Diesel Timer - DISL
3 ~ 99
2 AUX1 output time 1 ~ 100
3 AUX2 output time 1 ~ 100
4 AUX3 output time 1 ~ 100
5 AUX4 output time 1 ~ 100
6 AUX5 output time 1 ~ 100
7
AUX6 output time 1 ~ 100
8
AUX7 output time
1 ~ 100
Special Option Group 2
Feature Setting and OP500 Value
Programmable
Output Connector
0 - Default Setting 1~19 – Optional Settings
1
POC #1 (-) 2nd Parking Light (Green/White)
2nd Light - [1] 2nd Start - [2] 2nd IG1 - [3]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] Defrost - [17] GWA - [18]
Status 2 For Manual Trans. - [19]
2
POC #2 (-) 2nd Start (Red/Black)
3
POC #3 (-) 2nd Ignition (Green)
4
POC #4 (-) 2nd Accessory (White/Black)
5
POC #5 (-) Status/GWR (Black)
6
POC #6
(-) Rearm Wire (Orange)
7 POC #7 (-) Disarm Wire (Orange/White)
8
POC #8
(-) Horn (White)
9
POC #9
(-) Auxiliary 1 (Violet)
Option Menu Descriptions CM6200
1-01 Unlock Before, Lock After Starting. Lock After Remote Start.
If enabled, this option will make the system unlock the doors before remote starting, start the vehicle,
then lock the doors after the vehicle starts. It will then lock the doors again if the remote start run time
expires and the vehicle shuts down. This feature is for vehicles that have factory alarms that need to be
disarmed before remote starting.
1-02 Door Lock/Unlock Pulse Duration.
This option determines the output duration of the door lock and unlock pulses. Some vehicles do not
respond to short door lock/unlock pulses.
1-03 Driver’s Priority Unlock - If enabled, this option will cause the system to unlock the driver’s door first,
and if the unlock button is pressed again within 3 seconds, the other doors will unlock. The driver’s door
must be isolated from the other doors. Use the Orange/Black CN4 for your 2nd Unlock output.
