Page 18

Copyright 2009 Firstech, LLC.
Page 18
Connector 10 (CN10), 2-Pin (Pre-wired LED)
Note: Do not mistake for Thermister port.
Pin 1 Black - L.E.D negative (-) ground.
Pin 2 Black/White- L.E.D. 3V positive (+) output.
Connector 11 (CN11), 3-Pin (Pre-wired Valet/Programming Switch)
Pin 1 Gray/Black - Negative (-) ground.
Pin 2 Gray – 3V positive (+) L.E.D. output.
Pin 3 Gray – Negative (-) output.
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Option Programming Tables CM6200
Option Group 1
Feature
Default Setting - I
Optional Setting - II
Optional Setting - III
Optional Setting - IV
1-01
Unlock before, Lock after,
starting
Off
On
Lock After Remote
Start Only
Lock After Shutdown
Only
1-02
Lock / Unlock pulse duration
0.8 sec
2.5 sec
0.125 sec
3.5 sec
1-03
Driver's priority unlock
Off
On
1-04
Double pulse unlock
Off
On
1-05
Rearm Output
After Start Shutdown
and First Lock
After Start Shutdown
and Every Lock
After Start Only
After Shutdown Only
1-06
Reservation Lock
(Manual transmissions)
Locks When Reserva-
tion Mode is Set
Does Not Lock When
Reservation is Set
Reservation Sets 10
Seconds After the Last
Door is Closed
1-07
Unlock / Disarm With Trunk
Release
Unlock, Factory Dis-
arm, and Trunk Release
Factory Disarm, Trunk
Release Only
Trunk Release Only
1-08
Passive Mode
Off
Passive locking with
Passive Arming
No Passive Locking
with Passive Arming
1-09
Ignition controlled door locks
Off
On
RPM Locks (Tach
Sensing Mode Only)
1-10
Auto Relock
(If a door is not opened within
this amount of time)
Off
30 sec
60 sec
5 min
1-11
Ignition / Accessory Out Upon
Unlock
Off
Ignition Pulse - same
timing as disarm pulse
Acc Pulse - same tim-
ing as disarm pulse
Ignition and Acc
Pulse - same timing as
disarm pulse
1-13
Double Pulse Disarm Input
Single Pulse
Double Pulse
1-14
Auto Lock Mode
(2 Way International Remotes)
Off
On
1-15
Trunk Output Timing
1 sec
0.5 sec
2 sec
