Parts – FMI VSGF36NRC User Manual
Page 35
www.fmiproducts.com
121082-01K
35
KEY
NO. PART NO.
DESCRIPTION
QTY.
1
113190-01CK Screen
2
2
116865-01CK Bottom Louver Assembly
1
3
**
Face Weldment
1
4
101355-03CK Hood
1
5
116864-01CK Louver Assembly
1
6
**
Firebox Bottom Bracket
1
7
**
Right Firebox Support Leg
1
8
**
Left Firebox Support Leg
2
9
**
Firebox Surround
1
10
**
Firebox Top Shield
1
11
**
Firebox Top
1
12
**
Damper Can Collar
1
13
**
Insulation Pan
1
14
**
Fireplace Top Insulation
1
15
**
Fireplace Top
1
16 20280
Top Spacer
4
17
**
Fireplace Surround
1
18 107128-01
Gas Conduit
2
19 115408-01
Receptacle Plate
1
20 21171
Gas Knock-Out Cover
4
21 103771-01
Strain Relief
1
22 115402-01
Steel Receptacle Box
1
23 119943-01
Blower
1
24 M11084-38
Hex Screw, #8
3
25 GA3555
Duplex Outlet
1
26 115403-01
Steel Receptacle Cover
1
27 101378-01
Thermostat Switch
1
28 117539-01
Brick Refractory Kit
1
29 117891-01
FPH Handle Bracket
4
** Not a field replaceable part.
PARTS
MODELS VSGF36PRC AND VSGF36NRC
This list contains replaceable parts used in your firebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 31 of this manual.
