Installation Requirements
4-10 C141-E235
4.3.2 Interface connector
The connector for the Fibre Channel Loop is an unshielded SCA-2 connector which has two 20-
pin rows spaced 1.27 mm (0.05 inch) apart. Figure 4.10 shows the connector. See Appendix A
for signal assignments on the connector.
For details on the physical/electrical requirements of the interface signals, refer to Section 1.3
“Physical Requirements, Electrical Requirements” of the Fibre Channel Interface Specifications.
Figure 4.10 SCA2 type connector
