10
HOW tO PRImE tHE WAtER SUPPLY SYStEm
Your refrigerator’s water supply system includes several tubing
lines, a water filter, a water valve and a water tank.
to ensure
that your water dispenser works properly, this system must
be completely filled with water when your refrigerator is
first connected to the household water supply line and
whenever you replace the water filter.
to PriMe the Water suPPLY sYsteM:
• Begin filling the tank by pressing and holding a drinking
glass against the water dispenser paddle.
• Keep the glass in this position until water comes out of
the dispenser. There will be noticeable spurts and
sputters as the system pushes air out through the
system and dispenser nozzle. This is normal. this may
take about 1½ minutes.
• Continue dispensing water for about 3 minutes to flush
the system of any air and impurities. Empty glass as
needed.
HOW tHE ICE mAKER WORKS
AUtOmAtIC ICE & WAtER DISPENSER (CONtINUED)
AUtOmAtIC ICE & WAtER DISPENSER OPERAtING INStRUCtIONS
features may vary according to model.
Crushed Press the Crushed Touch Pad to get crushed ice. A red indicator will appear above the Touch Pad.
Press glass against ICE dispensing paddle as far up as possible to catch all ice.
Cubed Press the Cubed Touch Pad to get cubed ice. A red indicator will appear above the Touch Pad.
Press glass against ICE dispensing paddle as far up as possible to catch all ice.
Light On Press the Light On Touch Pad to turn on dispenser light. A red indicator will appear above the
Touch Pad.
Light Off Press the Light Off Touch Pad to turn off dispenser light. A red indicator will appear above the
Touch Pad.
Water To operate the water dispenser, press a glass against the WATER dispensing paddle . To stop
dispensing water, pull the glass away from the dispensing paddle . Dispensed water is not cold.
For colder water, add crushed ice or cubes before dispensing water. A drip tray located at the base
of the dispenser catches small spills and allows them to evaporate. This drip tray is removable and
dishwasher safe. Do not pour water and excess ice in this area because there is no drain.
4
3
2
1
5
6
5
6
5
4 3 2 1
6
CAUtION
for proper dispenser operation, recommended water
supply pressure should fall between 30 psi and 100 psi.
Excessive pressure may cause water filter to malfunction.
NOtE
The water dispenser has a built-in device that shuts off the
water flow after 3 minutes of continuous use. To reset this
shutoff device, simply release the dispenser paddle.
CAUtION
Chemicals from a malfunctioning softener can damage the
ice maker. If the ice maker is connected to soft water, ensure
that the softener is maintained and working properly.
ImPORtANt
Your ice maker is shipped from the factory with the wire
signal arm in the ON position (side mounted) or with the
switch turned ON (rear mounted). To ensure proper function
of your ice maker, hook up water supply immediately or turn
ice maker OFF by lifting the wire signal arm until it clicks
and locks in the UP position (side mounted) or turn the
On/
Off switch to the Off (0) position. If the ice maker is not
turned off and the water supply is not connected, the
water valve will make a loud chattering noise.
