7.3 SHPF and SHPM Pump Curves
0.0
20.0
40.0
60.0
80.0
100.0
120.0
0 50 100 150 200 250
0
10
20
30
40
50
Feet of
Head
P S I
Jandy ® Stealth Series High Head Pumps
Full Rated (SHPF) and Max-Rated (SHPM)
Flow Rate (GPM)
2 HP SHPF/
2.5 SHPM
3 HP SHPF
1.5 HP SHPF/
2.0 HP SHPM
1 HP SHPF/
1.5 HP SHPM
0.75 HP SHPF/
1.00 HP SHPM
2.5 HP SHPM/
LOW SPEED
2.0 HP SHPM/
LOW SPEED
