11

Transducer connected to the ETR-30N is not programmed in the ETR-30N

For the transducer not programmed in the ETR-30N, enter its frequency manually as below.

Do not enter transducer specifications
manually if the transducer is programmed
in the equipment.

The transducer may become damaged.

CAUTION

1. Follow the procedure on page 7 to shown the INSTALLATION SETUP menu.
2. Press the NETWORK SOUNDER SETUP soft key.
3. Press the FREQ SETUP soft key.
4. Press the EDIT soft key.

MODEL NUMBER

MANUAL

TRANSDUCER SETUP

Transducer type setting options

5. Use the [ENTER] knob to select MANUAL and then push the [ENTER] knob.
6. Use the [ENTER] knob to choose HIGH FREQUENCY and then push the [ENTER]

knob.

12.0kHz

HIGH FREQUENCY

Frequency input screen

7. Use the [ENTER] knob to choose frequency (setting range: 25 kHz-220 kHz) and then

push the [ENTER] knob. Currently, 12-24.8 kHz and 221-420 kHz cannot be set. These
frequencies are for future use.

8. If a low-frequency transducer is installed, set it similarly.
9. Turn off the NavNet display unit.
10. Turn on the Navnet display unit. Confirm that the echo sounder picture advances.
