5
Insert Screws Here
• Insert two #10 x 2,2 cm black screws through the footrest and
into the seat bottom. Tighten the screws. This may require
extra force.
Assembly
4
Seat Back Pin
• Turn the seat bottom assembly upright.
• Fit the seat back pins into the slots in the top side of the seat
bottom assembly.
Slot
Seat Bottom Assembly
Slot
5
• Turn the seat assembly face down.
• Insert the hinge rod through the hinge on the seat back and seat
bottom, as shown.
• Insert a #10 x 2,2 cm black screw into the hinge rod. Tighten
the screw.
• Set the seat assembly aside for Assembly step 9.
Hinge
Hinge Rod
6
