Page 4

IMPORTANT! Before assembly and each use, inspect this product
for damaged hardware, loose joints, missing parts or sharp edges.
DO NOT use if any parts are missing or broken. Contact Fisher-Price

for replacement parts and instructions if needed. Never substitute parts.

Footrest

Seat Bottom

• Place the seat bottom face down on a flat surface.
• At an angle, fit the footrest on the seat bottom, as shown.

Seat Bottom Tubes

• Slide a seat bottom tube through each set of plastic rings on the

seat bottom.

Plastic Rings

Assembly

• Align the holes in the plastic rings and the seat bottom tubes.
• Insert a #8 x 1,9 cm screw through each plastic ring and into

the seat bottom tubes, as shown. Tighten the screws. This may
require extra force.

• Push the seat bottom tubes back and forth to be sure they are

secured to the seat bottom. If the seat bottom tubes move,
you have probably not fastened them properly. Remove the
screws and check to be sure the screw holes in the seat bottom
tubes and seat bottom plastic rings are aligned. Replace and
tighten the screws.
