Handle

Latch

• Using a slotted screwdriver, turn both lock fasteners ¼

turn to the

locked position

• First, “snap” the front of the seat to the vehicle

• Next, “snap” the four tabs near the back of the seat into the matching

slots in the vehicle

LOCKED

UNLOCKED

• Position both seat belts so that the fasteners face each other,

as shown.

• Insert the T-loop end of each seat belt through the slot in each side

of the seat.

• Pull up on the seat belts to secure them to the seat.

T-Loops

Seat Belt
Fasteners

• Make sure the front wheels are not turned.

• Locate the latch on the back end of the vehicle.

• Press the tab and slide the latch to open.

• Insert the handle, as shown, and release the tab.

Note: Be sure the end of the handle is clean and free from debris
before inserting.

IMPORTANT! If the latch closes, the handle is properly inserted.
If it does not, remove the handle and repeat this step.

ASSEMBLY

SIDE VIEW
