Page 11
DESCRIPTION OF CONTROLS
Fuel Valve
The fuel valve controls fuel flow from the fuel tank to the carburetor.
The fuel valve must be ON to start and operate the mower. The fuel
valve should be kept OFF when the mower is not in use.
Throttle Lever
CHOKE – – For starting a cold engine.
FAST – – – For restarting a warm engine and for mowing.
SLOW – – – For idling the engine.
Flywheel Brake Lever
This lever is connected to the
engine flywheel brake and the
engine switch. The engine will not
start or run unless this lever is
held against the handlebar.
OFF
ON
FUEL VALVE
CHOKE
FAST
SLOW
FLYWHEEL BRAKE LEVER
CONTROLS
9
