14
ID# M611412 04/05
11.
Attach net (8).
2.
4. 3.
1.
SAWHORSE OR SUPPORT TABLE
9. Support pole and tank assembly over support table. Carefully slide
backboard components onto pole.
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
DO NOT LEAVE
ASSEMBLY UNATTENDED
WHEN EMPTY; IT MAY TIP
OVER.
WARNING!
12
23
17
10.
Peel protective
film from surface
of acrylic
backboard prior
to use.
NOTE:
While still in the horizontal position, carefully
slide backboard components onto pole. Secure
hardware at desired position as shown and
tighten all hardware completely at this time.
