Healthrider HREX04981 - Manual (Page 14)

14
1
1
Frame
2
1
Front Stabilizer
3
1
Rear Stabilizer
4
1
Left Side Shield
5
1
Right Side Shield
6
1
Upright
7
1
Resistance Knob
8
1
Resistance Control
9
1
Console
10
2
Handlebar Foam
1
1
1
Seat Carriage
12
1
Seat
13
1
Seat Back
14
2
Cup Holder
15
2
Handlebar Endcap
16
1
Handlebar
17
3
M8 x 45mm Button Screw
18
1
Extension Wire
19
1
Pulley
20
3
Console Screw
21
5
M4 x 25mm Screw
22
2
Pulse Wire
23
1
Frame Endcap
24
4
M8 x 40mm Button Bolt
25
8
#8 x 1/4Ó Screw
26
2
Seat Carriage Bushing
27
1
Seat Frame
28
7
M8 Curved W
asher
29
4
M6 x 15mm Hex Screw
30
1
#10 x 5/8Ó Screw
31
1
Magnet
32
2
Crank Bearing
33
1
Crank
34
2
Crank Arm
35
2
M8 x 20mm W
asher Screw
36
2
Crank Cap
37
1
Right Pedal
38
1
Right Pedal Strap
39
1
Crank Nut
40
1
Left Pedal
41
1
Left Pedal Strap
42
2
Front Stabilizer Endcap
43
2
#4 x 3/8Ó Screw
44
1
Reed Switch/Wire
45
1
M10 Nylon Jam Nut
46
1
Idler Bushing
47
1
Idler Wheel
48
1
Idler Spacer
49
1
Idler Arm
50
1
M10 x 26mm Bolt
51
1
Idler Spring
52
1
M10 Nylon Locknut
53
2
M10 Black Flat W
asher
54
1
Stop Bolt
55
1
M8 x 45mm Hex Bolt
56
1
1
M8 Nylon Locknut
57
18
M8 Black Flat W
asher
58
1
Return Spring
59
1
ÒCÓ Magnet
60
1
M8 Zinc Flat W
asher
61
3
M4 x 44mm Screw
62
3
M4 x 63.5mm Screw
63
2
M8 x 80mm Carriage Bolt
64
2
Rear Stabilizer Endcap
65
1
Axle Spacer
66
1
Axle
67
1
Resistance Cable
68
1
Belt
69
1
M5 x 15mm Screw
70
1
Flywheel
71
2
Pulse Handle
Assembly
72
2
M8 x 70mm Carriage Bolt
73
4
M6 x 38mm Hex Screw
74
4
M8 x 15mm Button Screw
75
1
Roller
76
1
Roller Axle
77
2
M10 Black Nylon Locknut
78
1
Nut
79
1
Seat Knob
80
2
Star W
asher
81
1
Double-sided T
ape
#
1
User
Õs
Manual
#
1
Allen W
rench
Note: Т#У indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover of this man
ual for information about ordering
replacement parts.
EXPLODED DRA
WINGÑModel
No. HREX04981
R0199A
Key
No.
Qty
.
Description
Key
No.
Qty
.
Description
Key
No.
Qty
.
Description
