MS4120F; MS4620F; MS8120F; S2024-F; S20230-F FAST-ACTING, TWO-POSITION ACTUATORS
7
63-2584—10
Fig. 10. Typical 24 Vac wiring (S20 Series).
Fig. 11. Typical 230 Vac wiring (S20 Series).
M20678A
BLUE
BROWN
230 VAC
S2024-F-SW2, MS8120S
L1 ( )
L2 ( )
BLACK/BLUE
BLACK/RED
BLACK/YELLOW
GRAY/RED
GRAY/BLUE
GRAY/YELLOW
85° AUXILIARY
SWITCH
7° AUXILIARY
SWITCH
M20680A
BLUE
BROWN
230 VAC
S20230-F-SW2, MS4620S
L1 ( )
L2 ( )
BLACK/BLUE
BLACK/RED
BLACK/YELLOW
GRAY/RED
GRAY/BLUE
GRAY/YELLOW
7° AUXILIARY
SWITCH
85° AUXILIARY
SWITCH
