Fig. 4 fig. 2, Fig. 3 – Hotpoint DE47X1 User Manual

Page 40

background image

40

GB

570mm

exc. hand

le

knobs

882mm

595mm

561mm

562mm

870mm

882mm,

870mm if

cooker trim

is to overlap

top edge

of shelf

* excluding pipe work
and other projections

4mm

2

Cable
To Oven

Connector

Box

Fig. 4

Fig. 2

550mm

550mm

min *

562mm

Viewed down through cabinet

No. 6x25mm screw
(4 supplied)

Oven Door

Fig. 3

Cabinet

6mm

2

Cable

if hob fitted

4mm

2

Cable

to Hob if

if fitted
