-E25-
To distinguish the A, B, C, D, E and F used in the hexadecimal base
from standard letters, they appear as shown in the below.
Key
Display
(Upper)
Display
(Lower)
Key
Display
(Upper)
Display
(Lower)
A /A D ID
B IB E IE
C I C F IF
Select the number base you want to use with [ BIN ], [ OCT ],
[ DEC ], [ HEX ]. The " BIN ", " b ", " OCT ", " o ", " HEX ", " h "
indicators show you which number base you are using. If none of the
indictors appears in the display, you are in decimal base.
Bases conversions
¾
37 (base 8) = 31 (base 10) = 1F (base 16)
DEG OCT [ 2nd ] [ OCT ] 37
0 0 0 0 0 0 0 0 0 3 7
o
DEG [ 2nd ] [ DEC ]
3 1 .
DEG HEX [ 2nd ] [ HEX ]
0 0 0 0 0 0 1 F
h
Block Function
For a result in binary base, it will be displayed using block function.
The maximum of 32 digits are displayed in 4 blocks of 8 digits.
1 1 0 1 0 0 1 1 b
DEG BIN
Indicates total blocks : 1 block
Indicates Block 1 presently displayed
Indicates Block 2 presently displayed
Indicates Block 3 presently displayed
Indicates Block 4 presently displayed
Indicates total blocks : 2 blocks
Indicates total blocks : 3 blocks
Indicates total blocks : 4 blocks
The block function comprises upper and lower block indicators. The
upper indicator means current block position, and the lower indicator
means total blocks for a result.
