Huffy P/N 21147703 - Manual (Page 13)

03/04 P/N 21147703
13
3.
Rotate non-secured ends of tank struts (16) outward to mounting holes in tank as
shown.Secure ends of tank struts (16) to tank as shown. Repeat for opposite side.
9
10
11
10
16
16
4.
10
10
14
17 13
16
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
IMPORTANT!:
Secure tank struts (16) to pole as shown.
Nut should be tightened until flush (even)
with locknuts outer edge. Place cap (17)
over exposed end of bolt as shown.
