Page 13

1 Setting Up and Using Your PC

Connecting Devices

NOTE

Universal Serial Bus (USB) connectors can be used for USB accessories.
(For information about HP accessories, connect to HP’s web site

.) Most USB accessories are

automatically configured as soon as they are physically attached to the PC.
USB is supported by Window 2000, Windows 98 and Windows 95 SR 2.1 only.

Line Out Jack. The internal audio speaker is deactivated when you use the
Line Out jack. External speakers should have a built-in power supply.

Connecting the Monitor

Connect the monitor according to the model of graphics card you have, as
shown below.

VGA Connector 2

VGA

S-Video

VGA Connector 1

VGA

DVI-I (for digital
LCD monitors)

Matrox MGA 450

nVidia GeForce2 GTS

nVidia GeForce2 MX
