INSTALLING BATTERIES

1. Extend the tray so that the battery cover is fully exposed.
2. Press down on latch and lift the battery cover to open the

battery compartment.

3. Install or replace 4 “AA ” sized batteries in the battery

compartment according to the indications inside the
compartment.

4. Close the battery cover by pushing in the top end of the

battery door.

Replace the batteries if:

1. The weak battery symbol appears on the display.

2. Nothing appears on the display when the power is

switched on.

As the supplied batteries are for test only, they may be
discharged earlier than batteries you buy in stores. Replace all
batteries at one time (as simultaneous set). Use only 1.5V AA
alkaline batteries. Remove batteries when unit is not in use for
extended periods of time. Date and time will need to be reset
if batteries are removed or replaced. Clean contacts on battery
and in battery compartment with a soft dry cloth each time you
install batteries.

Note: Batteries are hazardous waste. Do not dispose of them

together with the household garbage.

USING THE AC ADAPTER

Note:

• Please unload the batteries when operating with an AC

adapter for an extended period of time. Leaving the
batteries in the compartment for a long time may cause
leakage, which may lead to damage to the unit.

• No batteries are needed when operating with an AC

adapter.
• Date and time will need to be reset if AC adapter is

unplugged and unit is without batteries.

1. Connect the AC adapter with the AC adapter jack in the
back of the unit as shown below.
2. Please use only the AC adapter included with this monitor.

Battery
Cover

Slide-Out
Tray

AC Adapter

Input: 100-240V~0.2A 50/60Hz

Output: 6V DC 1A 6W Max

Connect

AC Adapter

here
