Ilve s.p.a – ilve Majestic II Collection 60 Inch Freestanding Dual Fuel Range Parts List User Manual
Page 5
ILVE S.p.a.
UM15FDNS3_SSC 25/06/2020
UM15FDNS3_SSC
N°
Cod
Descrizione
Inglese
Qtà
1 EG9622001000808 PORTA COMPL 60 3V M07-15N INOX-CROM
TRIPLE GLASS 60 MAJ-N DOOR/ST
1
2 EA0916003000000
CERNIERA POR FO 60 MJ/STD '15 SOFT
OVEN DOOR HINGE 60 MJ / STD '15
2
3 EA1290002000000 DISTANZIALE OT H=5,5 MANIG POR INOX
BRASS SPACER FOR HANDLE
2
4 EA4270009000008 MAN/CORRIM CROMO MAJEST D=22 I=420 CHROME HANDLE MAJESTIC D=22 I=420 1
5 EA4355001000000
MOLLA (CLIP FISSAGGIO) VETRO INTERM
SPRING
6
6 EA5890004000000
PROFILO GUIDA VET DX NERO '15
INSIDE PROFILE
1
7 EA5890005000000
PROFILO GUIDA VET SX NERO '15
INSIDE PROFILE
1
8 EA5890006000000
PROFILO GUIDA VET SUP 60 NERO '15
UPPER PROFILE
1
9 EA7814008110000
VETRO INTERMEDIO 60 MUFF '15
INSIDE DOOR GLASS
1
10 EA7814009110000
VETRO INTERNO 60 MUFF '15
INSIDE DOOR GLASS
1
11 EA7851005000000 VITE APP VE EST MAJ M5 L19 CH8 OTT
SCREW
2
12 EG5405011000808 PORTA+CORN 60 M07/15 MD10N INOX-CR
DOOR+FRAMES 60 M07/15 MD10N
1
13 EG9860004000000
VETRO+SQ PORTA 60 M15
DOOR GLASS
1
14 ES6060001010000 RINFORZO MAN PO MAJ-FRON CASS PT100
REINFORCEMENT
2
Tav.-2-
