Page 3
ILVE S.p.a.
UM15FDNS3_SSC 25/06/2020
UM15FDNS3_SSC
N°
Cod
Descrizione
Inglese
Qtà
1 EG9624005000808 PORTA COMPL 80 3V M09-15N INOX-CRO
TRIPLE GLASS 80 MAJ-N DOOR/ST
1
2 EA0916011000000
CERNIERA POR FO 80 '15 SOFT CLOS
80 OVEN DOOR HINGES
2
3 EA1290002000000 DISTANZIALE OT H=5,5 MANIG POR INOX
BRASS SPACER FOR HANDLE
2
4 EA4270003000008 MAN/CORRIM CROMO MAJEST D=22 I=625 MAJESTIC CHROME HANDLE D=22 I=625 1
5 EA4355001000000
MOLLA (CLIP FISSAGGIO) VETRO INTERM
SPRING
6
6 EA5890003000000
PROFILO GUIDA VET SUP 80 NERO '15
INSIDE PROFILE
1
7 EA5890004000000
PROFILO GUIDA VET DX NERO '15
INSIDE PROFILE
1
8 EA5890005000000
PROFILO GUIDA VET SX NERO '15
INSIDE PROFILE
1
9 EA7814004110000
VETRO INTERNO 80 MUFF '15
INSIDE DOOR GLASS
1
10 EA7814006110000
VETRO INTERMEDIO 80 MUFF '15
INTERMEDIATE DOOR GLASS
1
11 EA7851005000000 VITE APP VE EST MAJ M5 L19 CH8 OTT
SCREW
2
12 EG5405004000808 PORTA+CORNICI 80 M09/12/15N INOX-CR DOOR+FRAMES 80 M09/12/15N INOX-CR 1
13 EG9860003000000
VETRO+SQ PORTA 80 M15
DOOR GLASS
1
14 ES6060001010000 RINFORZO MAN PO MAJ-FRON CASS PT100
REINFORCEMENT
2
Tav.-1-
