11 / EN Microwave Oven / User Manual
2 Your microwave oven
3.1 Countertop installation
Remove all packing material and acces-
sories. Examine the oven for any dam-
age such as dents or broken door. Do not
install if oven is damaged.
Cabinet: Remove any protective film
found on the microwave oven cabinet
surface. Do not remove the light brown
Mica cover that is attached to the oven
cavity to protect the magnetron.
3.2 Installation
• Select a level surface that provide eno-
ugh open space for the intake and/or
outlet vents.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
• A minimum clearance of 3.0 inches
3 Installation
(7.5cm) is required between the oven
and any adjacent walls. One side must
be open. The minimum installation he-
ight is 3.0ft(91.6cm).
• Leave a minimum clearance of 12 inc-
hes (30cm) above the oven.
• Do not remove the legs from the bot-
tom of the oven.
• Blocking the intake and/or outlet ope-
nings can damage the oven.
• Place the oven as far away from radios
and TV as possible. Operation of mic-
rowave oven may cause interference to
your radio or TV reception.
• Plug your oven into a standard house-
hold outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
C
The trim kit Beko MWOKT
30100 SS is required for
built-in use. And the installa-
tion information contained in
trim kit installation manual of
Beko MWOKT 30100 SS.
2.3 Installing the turntable
• Never place the glass tray upside
down. The glass tray should never be
restricted.
• Both glass tray and turntable support
must always be used during cooking.
• All food and containers of food must
always place on the glass tray for co-
oking.
• If glass tray or turntable support crack
or break, contact your nearest authori-
zed service center.
Göbek (alt kısım)
Cam tabla
Döner tabla desteği
Döner tabla mili
Hub (underside)
Glass tray
Turntable shaft
Turntable support
